What is Pattern (Casting)?

Definition of Pattern:

Pattern is a replica of the required casting to be cast. Pattern is used to create a cavity in mold into which molten metal is poured during the casting process.

This pattern is used in sand casting process.

Material used for Patten:

  • Wood
  • Metal
  • Plastic
  • Thermocol
  • Wax (In Special Case)
  • Plaster of Paris (In Special Case)

Type of Pattern:

  • Single Piece Pattern
  • Split or two piece pattern
  • Match plate pattern
  • Cope & Drag Pattern
  • Gated Pattern
  • Sweep Pattern
  • Skeleton Pattern
  • Shell Pattern
  • Loose Piece Pattern
  • Flow Board Pattern
  • Loose Piece Pattern
  • Segmental Pattern
  • Left & Right Hand Pattern
  • Lagged-up Pattern
  • Built Type Pattern

Pattern Allowances
